BLD250-RS485 Brushless DC Motor Driver 18–60V Input, 250W Output

BLD250-RS485 Brushless DC Motor Driver 18–60V Input, 250W Output

Availability: In stock
₹ 2,900.00 (Inc.GST)
₹ 2,900.00 (Inc.GST)
Sale Sold out
Shipping calculated at checkout.

9270303

Short Description:
  1. Output current : 7.5A(Max).
  2. Voltage : 18-60V
  3. Equipped with LED indicator.
  4. Potentiometer with switch function for PWM adjustment.
  • Need Support?
    Click Here
  • Have a Bulk Order?
    Click Here
  • Free Delivery
    above ₹699
  • 1 Months Warranty
View full details
  • Description
  • Specification
  • Warranty
  • Questions
  • Other Information
Parameter Specification
Model BLD250
Motor Type Supported 3-phase Brushless DC Motor (BLDC)
Rated Power 250 W
Input Voltage Range 18 – 60 V DC
Operating Voltage 12 – 58 V DC
Rated Voltage 48 V DC
Output Current 7.5 A
Rated Speed Range 0 – 20,000 RPM
Hall Sensor Support Yes (closed-loop control)
Speed Control External potentiometer / analog / PWM
Direction Control Forward / Reverse supported
Protection Features Over-voltage, under-voltage, alarm signal output
Dimensions  136 × 82 × 30 mm
Weight 300 g
Cooling Method Natural air cooling
Operating Temperature -20°C to 50°C
Application Compatibility Robotics, automation, industrial machines

The Xrobo.in BLD250 W brushless DC motor driver designed to control 3-phase BLDC motors with Hall sensor feedback. It supports both manual and external speed control and provides smooth operation with high starting torque and quick response.

Application :

  • Industrial automation and machinery
  • Robotics and robotic motion control
  • Conveyor and packaging systems
  • CNC machines and precision equipment
  • AGV and mobile robot drive systems

Wires Connection:

  • Yellow : U
  • Green : V
  • Blue : W

Driver Connection:

  • HU = Yellow
  • HV    = Green
  • HW  = Blue
  • REF+ = Red
  • REF- = Black
  • F/R = Direction Level
  • EN = Enable
  • ALM = Light Signal Output Port
  • COM = External potentiometer GND
  • SV = External potentiometer Signal
  • D+ = RS485
  • D- = RS485
  • RV = Speed potentiometer

Packing List Includes:

1 x BLD250-RS485 Brushless DC Motor Driver 250W

The product has a warranty for 1 Months against manufacturing defects only.

However if the product is not used appropriately and is subject to tampering, accident, water damage, fire damage, chemical application & wires soldered or altered in any way the warranty will be void.
