| Parameter | Details |
|---|---|
| Model | SkyDroid C12 |
| Gimbal Type | 3-Axis Stabilized Gimbal |
| Visible Camera Resolution | 2560 × 1440 (2K) |
| Thermal Camera Resolution | 384 × 288 |
| Video Transmission Resolution | 1280 × 720 |
| Zoom Capability | 4× Digital Zoom |
| Thermal Lens | 7 mm |
| Thermal Aperture | F1.0 |
| Video Output | LAN Port / RTSP |
| Control Interface | LAN Port |
| Working Voltage | 7.2V – 72V |
| Working Current | 210mA |
| Weight | 117 g |
| Dimensions | 62 × 65 × 86 mm |
| Pitch Range | −90° to +10° |
| Yaw Range | −90° to +90° |
| Roll Range | −45° to +45° |
| Storage Support | MicroSD up to 256GB |
| Operating Temperature | −10°C to +50°C |
| Stabilization Accuracy | 0.1° |
The SkyDroid C12 for affordable thermal UAV applications because it combines thermal imaging and stabilized visible-light video in a lightweight package. Community users report that RTSP streaming over Ethernet is supported, although documentation and advanced SDK integration can be limited compared to enterprise systems.
Key Features:
- Dual visible-light and thermal imaging system
- Industrial-grade 3-axis stabilization
- Dynamic AI target tracking support
- LAN port with RTSP video output
- Lightweight 117 g UAV payload
- Supports upright and inverted mounting
- Compatible with drones, vehicles, and marine platforms
- Real-time video transmission and monitorin
Packing List Includes:
1 X SkyDroid C12 Thermal & 2K HD Camera with Three-Axis Gimbal
