T-Motor X-A12XL-18S Coaxial modular propulsion for Agricultural Drone

T-Motor X-A12XL-18S Coaxial modular propulsion for Agricultural Drone

Availability: Pre-order – Shipped within 10-15 days
₹ 118,900.00 (Inc.GST)
₹ 118,900.00 (Inc.GST)
Sale Sold out
Shipping calculated at checkout.

9360033

Short Description:
  • 100–120 kg MTOW coaxial quadcopters
  • Up to 180 kg MTOW hexacopters
  • 50L–70L spraying drones
  • High-capacity fertilizer / pesticide systems



  • Need Support?
    Click Here
  • Have a Bulk Order?
    Click Here
  • Free Delivery
    above ₹699
  • 1 Months Warranty
View full details
  • Description
  • Specification
  • Warranty
  • Questions
  • Other Information
Category Specification
Model X-A12XL KV64
System Type Coaxial modular propulsion (dual motor arm)
Configuration X-A12XL Motor ×2 + 18S FOC 150A ESC + PFZ4918P Prop
Recommended Battery 14–18S LiPo
Rated Thrust (per arm) 30–35 kg
Max Thrust (per arm) 73.4 kg
Efficiency ~8.2 g/W (at ~31 kg thrust)
Weight (system) ~4.8–5.2 kg
Ingress Protection IPX6
Operating Temperature -20°C to 55°C
Tube Size 50 mm
Wire Length ~1685–1700 mm

The X-A12XL-18S is a heavy-lift coaxial propulsion system designed for large industrial drones.

It is specifically recommended for:

  • 120 kg quadcopters
  • 180 kg hexacopters

Key Features:

  • Coaxial design (dual motor per arm) → double thrust in same footprint
  • ~73 kg max thrust per arm → extremely high lift capability
  • Compact heavy-lift solution → fewer arms needed
  • FOC ESC (150A) → smooth, efficient control
  • IPX6 rating → resistant to rain, dust, agriculture chemicals
  • CAN support → compatible with advanced flight controllers

Packing List Includes:

  • 1 × X-A12XL-18S Coaxial modular propulsion Dual Arm (Motor + ESC + Propeller)
  • 1 x Accessories pack

The product has a warranty for 1 months against manufacturing defects only.

However if the product is not used appropriately and is subject to tampering, accident, water damage, fire damage, chemical application & wires soldered or altered in any way the warranty will be void.
