T-Motor Thunder 300A 24S ESC

T-Motor Thunder 300A 24S ESC

Availability: Pre-order – Shipped within 15-20 days
₹ 150,000.00 (Inc.GST)
₹ 150,000.00 (Inc.GST)
Sale Sold out
Shipping calculated at checkout.

9360006

  • Need Support?
    Click Here
  • Have a Bulk Order?
    Click Here
  • Free Delivery
    above ₹699
  • 1 Months Warranty
View full details
  • Description
  • Specification
  • Warranty
  • Questions
  • Other Information
Parameter Specification
Product Name Thunder 300A 24S High-Voltage ESC
Supported Battery 14S – 24S
Maximum Input Voltage ~100 V
Continuous Current 240 A
Peak Current 300 A
Weight (with cables) ~870 g
Dimensions ~155 × 70 × 49 mm
BEC Output None
Throttle Input PWM (1000–2000 μs)
Signal Frequency PWM 50–400 Hz / High-speed digital support
Protection Functions Over-voltage, under-voltage, over-current, over-temperature, stall protection
Application Heavy-lift UAVs, manned aircraft propulsion systems

The Thunder 300A 24S High-Voltage ESC is a heavy-duty electronic speed controller designed for large UAVs and manned aircraft propulsion systems. Built to handle extremely high voltage and current levels, it ensures smooth motor control, reliable power delivery, and safe operation in demanding heavy-lift and industrial aerial applications.

Key Features:

  • Supports 14S–24S LiPo battery systems for high-voltage operation
  • High continuous current capability of 240A with 300A peak output
  • Optimized for large, high-power brushless motors
  • Advanced protection features for safe and reliable operation
  • Real-time telemetry feedback for voltage, current, RPM, and temperature
  • Robust thermal design for continuous heavy-duty usage

Packing List Includes:

  • 1 × Thunder 300A ESC

1 months from date of supply against manufacturing defects only.
