DALY LiFePO4 16S 50A Smart Battery BMS

DALY LiFePO4 16S 50A Smart Battery BMS

Availability: Out of stock
₹ 1,680.00 (Inc.GST)
₹ 1,680.00 (Inc.GST)
Sale Sold out
Shipping calculated at checkout.

7920045

Short Description:
  • Charge Voltage (V) : 51.2
  • Charge Current (A) : 50A
  • Balance Current (mA) : 30±5
  • Working Current (uA) : 100
  • Need Support?
    Click Here
  • Have a Bulk Order?
    Click Here
  • Free Delivery
    above ₹699
  • 1 Months Warranty
View full details
  • Description
  • Specification
  • Warranty
  • Questions
  • Other Information
Parameter Specification
Model DALY Smart BMS 16S 50A
Battery Chemistry LiFePO4 (Lithium Iron Phosphate)
Battery Configuration 16 Cells in Series (16S)
Nominal Battery Voltage 51.2 V
Full Charge Voltage 58.4 V
Continuous Charge Current 50 A
Continuous Discharge Current 50 A
Peak Discharge Current Up to 100–150 A
Balancing Current 50–70 mA
PC Monitoring Supported via UART/USB
Temperature Sensors 2 × NTC Sensors
Operating Temperature Charging: 0°C to +55°C; Discharging: −20°C to +60°C
Standby Power Consumption <1 W
Protection Rating IP65 waterproof, dustproof, and vibration-resistant construction
Dimensions 123 × 65 × 14–18 mm
Weight 300–450 g

The DALY LiFePO4 16S 50A Smart Battery BMS is an intelligent battery management system designed for 51.2V (16S) LiFePO4 battery packs. It provides 50 A continuous charge and discharge capability, passive cell balancing, comprehensive battery protection, and optional Bluetooth, UART, CAN, and RS485 communication for real-time monitoring. Its IP65-rated, rugged construction makes it well suited for solar energy storage, electric vehicles, marine systems, RVs, telecom backup power, and other professional lithium battery applications.

Key Features:

  • Designed for 16S LiFePO4 (51.2V nominal) battery packs
  • 50 A continuous charge and discharge current
  • Passive cell balancing for improved battery lifespan
  • Real-time battery monitoring via optional Bluetooth
  • Monitors:
  • Individual cell voltages
  • Total battery voltage
  • Charge/discharge current
  • State of Charge (SOC)
  • Battery temperature
  • Protection status and fault alarms
  • Supports UART, CAN, and RS485 communication (model dependent)
  • Compatible with Android, iOS, and PC monitoring software
  • Low standby power consumption
  • Waterproof, dustproof, and vibration-resistant enclosure
  • Available in common-port and separate-port configurations.

Packing List Includes:

  • 1 × DALY LiFePO4 16S 50A Smart Battery BMS

The product has a warranty for 1 months against manufacturing defects only.

However if the product is not used appropriately and is subject to tampering, accident, water damage, fire damage, chemical application & wires soldered or altered in any way the warranty will be void.
