Parameter |
Value |
|
System Voltage |
24 V DC nominal (max ~29 V) |
|
Throttle Output |
0.8–4.3 V analog (Hall sensor based) |
|
Key Switch Function |
On/Off latch, 2-position (removable key at Off) |
|
Key Switch Rating |
~24 V, typically 5–10 A (designed for controller enable or relay control, not direct battery main unless low current) |
|
Battery Meter Calibration |
~21 V (empty) to ~27 V (full) LED indication |
|
Connections |
Throttle: 3-wire to controller; Key: 2-wire to battery/controller; Meter: internally wired or additional 2-wire (if separate) |
|
Handlebar Size |
Fits standard 22 mm (7/8″) bars |
|
Included Keys |
2 metal keys |
|
Grip Length |
~half-twist throttle (about 120 mm length) |
|
Housing Material |
Durable ABS plastic with embedded electronics |
|
Indicator Type |
Usually 4-5 segment LED or colored LED bar for 24V |
|
Use Cases |
24V mobility scooters, kids electric go-karts, small EVs, electric wheelchairs (if handlebar-controlled) requiring user-friendly control and security |
