Parameter |
Value |
|
System Voltage |
Designed for 48 V DC battery systems |
|
Throttle Type |
Twist grip, Hall effect sensor (3-wire to controller) |
|
Key Switch Function |
2-position (Off/On), connects/disconnects 48V to controller ignition or main relay |
|
Key Included |
Yes, typically 2 keys provided |
|
Battery Indicator |
48V scale LED bar or digital display (e.g., 4-5 LED segments or 7-seg display) |
|
Indicator Range |
~42 V (empty) to ~54 V (full) calibration (for 48V nominal) |
|
Wiring Connections |
- Throttle: 3-pin (Red, Black, Signal) to controller<br/>- Key Switch: 2-pin (usually to controller’s lock wires or battery & controller enable)<br/>- Meter: 2-pin (often shared with key switch input, or separate to battery) |
|
Handlebar Fit |
Standard 7/8″ (22.2 mm) diameter |
|
Material |
Durable ABS plastic throttle housing, rubber grip |
|
Cable Length |
~1.5 m with split connectors for each function |
|
Additional Features |
Some models might include a built-in on/off button or horn button as well (varies) |
|
Usage |
48V e-bikes, electric go-karts, ATV, mobility scooters – where key security and battery gauge are desired |
