T-Motor A14-18S Modular Propulsion System for Agricultural Drone

T-Motor A14-18S Modular Propulsion System for Agricultural Drone

Availability: Pre-order – Shipped within 10-15 days
₹ 64,200.00 (Inc.GST)
₹ 64,200.00 (Inc.GST)
Sale Sold out
Shipping calculated at checkout.

9360031

Short Description:
  • 50L quadcopters (~100–108 kg takeoff)
  • 60L hexacopters (~150–162 kg takeoff)
  • Need Support?
    Click Here
  • Have a Bulk Order?
    Click Here
  • Free Delivery
    above ₹699
  • 1 Months Warranty
View full details
  • Description
  • Specification
  • Warranty
  • Questions
  • Other Information
Parameter Specification
Model A14-18S KV49.6
Product Type UAV Modular Propulsion System
Configuration Motor + 18S FOC 150A ESC + Propeller
Recommended Battery 18S LiPo
Max Voltage ~75V
Rated Thrust 25–27 kg
Max Thrust Up to 59–62 kg
Efficiency (Rated) ~9–10 g/W
Motor KV 49.6 KV
Stator Size ~138 × 25 mm
ESC Type FOC Intelligent ESC
Peak Current 150A (short duration)
Control Method PWM / CAN (Drone CAN, UAV CAN, Cube CAN)
Propeller Model MF56P (folding)
Propeller Size 56 inch (~1400 mm)
Weight (Full Set) ~4.0 – 4.3 kg
Tube Size 50 mm
Protection Rating IPX6
Operating Temp -20°C to +55°C

The T-Motor A14 18S UAV Modular Propulsion System is an ultra high-thrust propulsion system built for large-scale agricultural drones (50L–60L) and heavy industrial UAVs. It integrates a high-power motor, 18S FOC ESC, and 56-inch folding propeller, delivering extreme lifting capability, efficiency, and durability for high payload operations.

Key Features:

  • Agricultural spraying drones (50 L quadcopters, 60 L hexacopters)
  • Take-off Weight : 100-162Kg
  • Medium-lift multirotor UAVs
  • Surveying & industrial drones
  • Long-endurance flight systems needing robust propulsion

Packing List Includes:

  • 1 × A14-18S Modular Propulsion Arm (Motor + ESC + Propeller)
  • 1 x Folding propeller set
  • 1 x Accessories pack

The product has a warranty for 1 months against manufacturing defects only.

However if the product is not used appropriately and is subject to tampering, accident, water damage, fire damage, chemical application & wires soldered or altered in any way the warranty will be void.
