| Parameter | Specification |
|---|---|
| Model | FLAME 60A 12S V2.0 |
| ESC Type | Brushless Multi-Rotor UAV ESC |
| Continuous Current | 60 A |
| Peak Current | 80 A (10 seconds) |
| Input Voltage | 6S–12S LiPo (22.2–50.4 V) |
| BEC | No BEC |
| PWM Signal Frequency | 30–500 Hz |
| Throttle Range | 1100–1940 μs |
| Refresh Rate | Up to 500 Hz |
| Weight | 73.5 g (without cables) |
| Dimensions | 66.5 × 38.5 × 17.7 mm |
| Waterproof Rating | IP57 |
| Operating Temperature | -20°C to +65°C |
| Cooling Design | Layered heat dissipation structure |
| Protection Functions | Start-up, Signal Loss, Motor Lock-up, Overload Protection |
The T-Motor FLAME 60A 12S V2.0 is a professional-grade brushless ESC for industrial multirotor UAVs, delivering 60 A continuous and 80 A peak current with support for 6–12S LiPo batteries, advanced protection functions, and IP57-rated environmental protection.
Key Features:
- Supports 6S to 12S LiPo batteries
- 60 A continuous current output
- 80 A peak current for 10 seconds
- IP57-rated dust and water resistance
- Layered structure for excellent heat dissipation
- Optimized for industrial multirotor UAVs
- Built-in start-up protection
- Throttle signal loss protection
- Motor lock-up protection
- Overload and short-circuit protection
Packing List Includes:
- 1 × FLAME 60A 12S V2.0 UAV ESC
- 1 x 1 x Accessories pack
